Prolynx Professional Two Way Radio PL-900

Prolynx Professional Two Way Radio PL-900
PL-900 (Professional Two Way Radio) using for on-site medium range communications such as construction site, retail store, office environment, hotel & restaurants, hospitals, supermarkets, car…

PL-900 (Professional Two Way Radio) using for on-site medium range communications such as construction site, retail store, office environment, hotel & restaurants, hospitals, supermarkets, car dealership, education, property management etc…

Product Description

  • Dual band, Dual Display, Dual standby
  • 128 Channels
  • FM Radio Receiver
  • Channel Spacing Selectable (25/12.5KHz)
  • Output Power 10W
  • CTCSS/DCS Encoding and Decoding
  • 3600mAh Battery Capacity
  • 1750Hz Tone
  • Cross Band Repeater
  • High Gain Antenna
  • Handfree VOX Function
  • ANI Function
  • DTMF & Remote Kill/Stun Function
  • Reverse Frequency Function
  • Tri-Color Background Light Selectable
  • Emergency Alarm
GENERAL :
Frequency 136 – 174MHz and 400 – 520MHz
Frequency Stability ±2.5 PPm
Operating Voltage DC 7.2V (Rechargeable Li-ion Battery)
Channel No. 128
Antenna High Gain Antenna
Antenna Impedance 50Ω
Mode of Operation Simplex or Semi-Duplex
Battery Capacity 3600mAh
RECEIVER :
RF Sensitivity -122dBm (12dB SINAD)
Audio Power >0.5W
Audio Distortion <10%
Blocking ≥85dB
Intermediation ≥60dB ≥55dB
Selectivity ≥65dB ≥60dB
Spurious Rejection ≥65dB
TRANSMITTER :
Output Power ≤ 10W ≥5W
Modulation Mode 16kØF3E / 11kØF3E
Maximum Deviation <5KHz / <2.5KHz
Adjacent CH. Power ≤-65dB / ≤-60dB
Spurious Radiation < 7µW
Pre-Emphasis Characteristics 6dB
Current ≤ 2.8A (10W) ≤ 1.8A (5W)
CTCSS/DCS Deviation 0.55KHz ± 0.15KHz 0.4KHz ± 0.1KHz
Intermediation Sensitivity 8 – 12mV
Intermediation Distortion <5%
