Airmar B258 Thru-hull Transducer 1Kw

Airmar B258 Thru-hull Transducer 1Kw
  • epth and fast-response water-temperature sensing
  • 1 kW of power
  • Dual-frequency elements producing elliptical patterns for wider coverage
    • 50 kHz with a 15° x 21° beamwidth for depth performance to 647 m (2200')
    • 200 kHz with a 3° x 5° beamwidth for depth performance to 294 m (1000')
  • epth and fast-response water-temperature sensing
  • 1 kW of power
  • Dual-frequency elements producing elliptical patterns for wider coverage
    • 50 kHz with a 15° x 21° beamwidth for depth performance to 647 m (2200')
    • 200 kHz with a 3° x 5° beamwidth for depth performance to 294 m (1000')
  • Bronze-housing with High-performance Fairing for optimal performance at speed
  • Greater surface area resulting in better sensitivity
  • Patented Xducer ID® technology
  • Power Rating: 1 kW
    Max Deadrise Angle: 26°
    Housing: Bronze
    Functions: Depth, Temperature
    Hull Material: Fiberglass or wood
    Max Vessel LOA: 9 m (30') and above
    Hole Size: 30 mm (1-3/16")
    Usable Shaft Length: 121 mm (4.75")
    Acoustic Window: Epoxy/urethane
    Common Use: Leisure/Yachting, Fishing
    Conventional Beam: 15°x21°/3°x5°
    Max Deadrise: Up to 26° with fairing
    Max Depth: Low frequency- 647 m (2200'), High frequency- 294 m (1000')
    Mounting Style: Thru-Hull with Fairing
    Retractable housing: No
    Single or Dual Frequency: Conventional Dual Frequency
    Tilted Element: No
    Weight: 3.6 kg (7.9 lb.)
